Hitesh International manufacture and exports large variety of filter press machines for the separation of solids from liquids. Once the oil comes from Vibro separator to filter press small impurities are still present in the oil which is pumped to filter press for final filtration with the help of plunger pump.
Features:
1. Superior quality cast iron plates are used
2. Higher filtration rate
3. Plates are machined and grinded for accuracy which avoid leakages
| # | Size | Weight of Filter Press(kgs) |
Filtration Area (Sq.Mts) |
Capacity | Power | No. of Pistons |
Size of Plunger Pump |
|---|---|---|---|---|---|---|---|
| 1 | 36"X36"X36 Plates |
8,000 | 30 | 40,000 Litres/Day |
7.5 HP | Double | 80 mm |
| 2 | 30"X30"X30 Plates |
5,500 | 18 | 25,000 Litres/Day |
7.5 HP | Single | 75 mm |
| 3 | 24"X24"X30 Plates |
3,000 | 11 | 12,500 Litres/Day |
5 HP | Single | 60 mm |
| 4 | 24"X24"X24 Plates |
2,500 | 9 | 10,000 Litres/Day |
3 HP | Single | 60 mm |
| 5 | 18"X18"X18 Plates |
1,100 | 4 | 5,000 Litres/Day |
2 HP | Single | 40 mm |
| 6 | 14"X14"X14 Plates |
650 | 2 | 3,500 Litres/Day |
1 HP | Single | 30 mm |
| 7 | 12"X12"X12 Plates |
380 | 1.5 | 2,500 Litres/Day |
1 HP | Single | 30 mm |
| # | Size | Weight of Filter Press(kgs) |
Filtration Area (Sq.Mts) |
Capacity | Power | Pump |
|---|---|---|---|---|---|---|
| 1 | 36"X36"X36 Plates X 35 Frames | 9,600 | 30 | 48,000 Litres/Day |
10 HP | PCH PUMP |
| 2 | 36"X36"X30 Plates X 29 Frames | 5,400 | 18 | 25,000 Litres/Day |
7.5 HP | PCH PUMP |
| 3 | 24"X24"X24 Plates X 23 Frames | 2,950 | 10 | 10,000 Litres/Day |
5 HP | PCH PUMP |
